Lima Locomotive & Machine Co.

Photo Credit:
"Wisconsin Shortline and Logging Steam Locomotives," by Thomas E. Burg
Shop Number 2393 - Built for: A. H. Stange Co.
{1,832nd Lima Built Shay}
Built:
11-12-1910
Class:
B
28-2
Trucks:
2
Cylinders:
[#- Dia. x Stroke]
3 - 8 x 10
Gear Ratio:
3.071
Wheel Dia.:
27.5"
Gauge:
std.
Boiler:
[Style - Dia.]
E.W.T. - 35.375"
Boiler Pressure:
In Lbs. (PSI)
160
 Tractive Effort:
12,865 Lbs.
 Factor of
Adhesion:
4.95
 Maximum
Safe Speed:
10.7
Fuel Type:
Coal
Fuel Capacity:
1.75 Tons
Water Capacity:
1,050 Gallons
Empty Weight:
As built
51,000
Owners:
A. H. Stange Co. #3, Merrill, WI; For:
Union Land Co. #3, New Wood, WI
Kinzel Lbr. Co. #3, New Wood, WI
(11-30-1926) Bissell Lbr. Co. #3 (2nd), Ladysmith, WI
MacDonough Mfg. Co., Eau Claire, WI
Disposition: Scrapped
Additional Notes:
