Lima Locomotive Works, Inc.

Photo Credit:
George R. Kadelak collection (BP 8-1923)
Shop Number 3230 - Built for: Bennett & Brown Lbr. Co.
{2,647th Lima Built Shay}
Built:
8-8-1923
Class:
B
42-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
3 - 10 x 12
Gear Ratio:
2.05
Wheel Dia.:
29.5"
Gauge:
std.
Boiler:
[Style - Dia.]
E.W.T. - 42.125"
Boiler Pressure:
In Lbs. (PSI)
180
 Tractive Effort:
16,886 Lbs.
 Factor of
Adhesion:
5.56
Maximum
Safe Speed:
17.1
Fuel Type:
Coal
Fuel Capacity:
2 Tons
Water Capacity:
1,560 Gallons
Empty Weight:
As built
76,900
Owners:
Bennett & Brown Lbr. Co. #1, Bergland, MI
(8-6-1926) Changed gears to 2.5 to 1
(8-3-1928) Herman Holmes, Iron River, MI
Mississippi Valley Equip. Co. (D), Saint Louis, MO
(11-17-1936) Northwestern States Portland Cement Co. #1 (2nd), Mason City, IA
Disposition: Scrapped
Additional Notes:
