Lima Locomotive Works, Inc.
Photo Credit:
Left: George R. Kadelak collection (BP 12-1923)
Right:
John Nople collection
Shop Number 3245 - Built for: Dalkena Lbr. Co.
{2,661st Lima Built Shay}
Built:
12-22-1923
Class:
B
36-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
3 - 10 x 10
Gear Ratio:
2.05
Wheel Dia.:
29"
Gauge:
std.
Boiler:
[Style - Dia.]

E.W.T. - 39.375"
Boiler Pressure:
In Lbs. (PSI)
180
Tractive Effort:
14,315 Lbs.
Factor of
Adhesion:

5.99
Maximum
Safe Speed:

16.8
Fuel Type:
Oil
Fuel Capacity:
800 Gals.
Water Capacity:
1,200 Gallons
Empty Weight:
As built
71,300
Owners:
Dalkena Lbr. Co. #1, Priest River, ID
(1936) Diamond Match Co. #5, Albeni Falls, ID
(10-21-1942) Diamond Match Co. #105, Stirling City, CA
Disposition: (1954) Scrapped
Additional Notes:
