Lima Machine Works

Photo Credit:
No Photo At This Time
Shop Number 355 - Built for: J. F. Gamble
{318th Lima Built Shay}
Built:
5-7-1891
Class:
A
15-2
Trucks:
2
Cylinders:
[#-Dia. x Stroke]
2 - 7 x 12
Gear Ratio:
3.071
Wheel Dia.:
26"
Gauge:
36"
Boiler:
[Style - Dia.]

Boot - 36"
Boiler Pressure:
In Lbs. (PSI)
150
Tractive Effort:
7,913 Lbs.
Factor of
Adhesion:

3.48
Maximum
Safe Speed:

10.1
Fuel Type:
Wood
Fuel Capacity:
0.33 Cord
Water Capacity:
486 Gallons
Empty Weight:
As built
23,700
Owners:
J. F. Gamble #355, Abbott, TN
(c1901) A. Cameron & Co., Vass, NC
Disposition: Scrapped
Additional Notes:
