Lima Locomotive & Machine Co.

Photo Credit:
George R. Kadelak collection
Shop Number 625 - Built for: F.H. & C.W. Goodyear
{570th Lima Built Shay}
Built:
10-17-1900
Class:
C
65-3
Trucks:
3
Cylinders:
[#-Dia. x Stroke]
3 - 14 x 12
Gear Ratio:
2.056
Wheel Dia.:
33"
Gauge:
std.
Boiler:
[Style - Dia.]
W.T. - 48"
Boiler Pressure:
In Lbs. (PSI)
200
 Tractive Effort:
32,875 Lbs.
 Factor of
Adhesion:
4.41
 Maximum
Safe Speed:
19.2
Fuel Type:
Coal
Fuel Capacity:
6 Tons
Water Capacity:
2,693 Gallons
Empty Weight:
As built
114,600
Owners:
F.H. & C.W. Goodyear #6 (2nd), Austin, PA
Goodyear Lbr. Co., Potato Creek RR #6, Keating Summit, PA
Disposition: Scrapped
Additional Notes: F.H. & C.W. Goodyear was Frank Henry and his brother, Charles Waterhouse Goodyear
